DIN 20023- 4SH Four Spiral Tempered Wire Hoses
450 INR/Meter
Product Details:
- Shape Round
- Product Type Hydraulic Hose Pipe
- Color Black
- Material Rubber
- Temperature -40 to 120
- Warranty 12 Months
- Click to View more
X
DIN 20023- 4SH Four Spiral Tempered Wire Hoses Price And Quantity
- 50 Kilograms
- 450 INR/Meter
DIN 20023- 4SH Four Spiral Tempered Wire Hoses Product Specifications
- Rubber
- -40 to 120
- Round
- 12 Months
- Black
- Hydraulic Hose Pipe
DIN 20023- 4SH Four Spiral Tempered Wire Hoses Trade Information
- Cash in Advance (CID) Cash Advance (CA)
- 10000 Kilograms Per Day
- 1 Week
- Asia Australia Eastern Europe Western Europe Middle East Central America South America North America Africa
- All India
Product Description
Product Details:
| Color | Black |
| Nominal Size | 1/2'', 3/4'' |
| unit Length | 3m, 6m |
4SH – (Brand Name: GLOBAL)
DIN 20023- 4SH Four Spiral Tempered Wire
Application : Extra High Pressure Extra Heavy duty Hydraulic Oils, Air and water.
Const - Tube: Seamless Synthetic rubber, Reinforcement : 4 Spiral of High tensile Tempered Wire Braids.
Cover: Synthetic Rubber Weather, Oil and abrasion resistant. Temp Range -40 to 125 degree celsius
ID | OD | Max Working Pressure | Testing Pressure | Min Bursting Pressure | Min Bend Radius | ||
Inch | MM | MM | PSI | Bar | BAR | BAR | MM |
1/2" | 12.7 | 16.6 | 7000 | 510 | 1020 | 2040 | 200 |
5/8" | 15.9 | 28.5 | 6400 | 460 | 920 | 1840 | 240 |
3/4" | 19 | 32 | 6090 | 420 | 840 | 1680 | 280 |
1" | 25.4 | 39 | 5510 | 385 | 770 | 1540 | 340 |
1-1/4" | 31.8 | 45.5 | 4710 | 350 | 700 | 1400 | 460 |
1-1/2" | 38.1 | 53.5 | 4200 | 300 | 600 | 1200 | 560 |
2" | 50.8 | 68.1 | 3630 | 250 | 500 | 1000 | 700 |
